High-precision, high-speed lathe
L280MY-F
High-speed
High precision
For small and medium-sized precision parts
Retail Price
Market price
Supplier:
Suzhou
China
Weight
Stock surplus
隐藏域元素占位
- Product Description
- Product specifications and models
-
- Brand: mx
- Commodity name: High-precision, high-speed lathe
- 型号: L280MY-F
- 特点01: High-speed
- 特点02: High precision
- 特点03: For small and medium-sized precision parts
- 供应商: Suzhou
- 地址: China
High-speed precision lathes L260 L270 L280MY series
Maixing CNC lathes are high-precision, high-speed, full-featured CNC lathes, a new generation of world-standard machines, capable of widely meeting the high-efficiency processing needs of various industries such as automobiles, electronics, home appliances, aerospace, molds, and instrumentation for small and medium-sized precision parts. -
Maximum swing diameter
mm
500
Maximum machining diameter
mm
536
Distance between spindle face and turret face
mm
61-521
Maximum machining length
mm
420
Output power ( 30min/ continuous)
kw
17
Spindle structure
-
Electric spindle
Spindle end form
-
A2-6
Spindle speed
rpm
4500
Chuck
in
8(10)
Spindle through-hole diameter
mm
φ 62(76)
Bar stock passing capacity (must select control oil cylinder , chuck)
mm
φ 51(65)
C Axis (compensating linkage axis) indexing
。
0.001
X Axis stroke
mm
185
Y Axis stroke
mm
± 50
Z Axis stroke
mm
460
X Axis rapid traverse speed
m/min
30
Y Axis rapid traverse speed
m/min
12
Z Axis rapid traverse speed
m/min
36
Turret type
-
Servo turret
Tool capacity
ea
12
Tool indexing time
sec/step
0.2
Power turret
BMT
55
Turning tool body size
mm
25*25
Maximum boring bar diameter
mm
φ 40
Milling spindle power
kw
4
Milling spindle speed
rmp
6000
Type
-
Hydraulic tailstock / Servo tailstock
Taper hole type
-
MT4 （ MT5)
Main body travel
mm
500
Main body travel speed
m/min
10
Previous Page
Next Page
Product specifications and models
Maximum swing diameter | mm | 500 |
Maximum machining diameter | mm | 536 |
Distance between spindle face and turret face | mm | 61-521 |
Maximum machining length | mm | 420 |
Output power ( 30min/ continuous) | kw | 17 |
Spindle structure | - | Electric spindle |
Spindle end form | - | A2-6 |
Spindle speed | rpm | 4500 |
Chuck | in | 8(10) |
Spindle through-hole diameter | mm | φ 62(76) |
Bar stock passing capacity (must select control oil cylinder , chuck) | mm | φ 51(65) |
C Axis (compensating linkage axis) indexing | 。 | 0.001 |
X Axis stroke | mm | 185 |
Y Axis stroke | mm | ± 50 |
Z Axis stroke | mm | 460 |
X Axis rapid traverse speed | m/min | 30 |
Y Axis rapid traverse speed | m/min | 12 |
Z Axis rapid traverse speed | m/min | 36 |
Turret type | - | Servo turret |
Tool capacity | ea | 12 |
Tool indexing time | sec/step | 0.2 |
Power turret | BMT | 55 |
Turning tool body size | mm | 25*25 |
Maximum boring bar diameter | mm | φ 40 |
Milling spindle power | kw | 4 |
Milling spindle speed | rmp | 6000 |
Type | - | Hydraulic tailstock / Servo tailstock |
Taper hole type | - | MT4 （ MT5) |
Main body travel | mm | 500 |
Main body travel speed | m/min | 10 |
Product Introduction
High-speed precision lathes L260 L270 L280MY series
Maixing CNC lathes are high-precision, high-speed, full-featured CNC lathes, a new generation of world-standard machines, capable of widely meeting the high-efficiency processing needs of various industries such as automobiles, electronics, home appliances, aerospace, molds, and instrumentation for small and medium-sized precision parts.
