4-axis CNC machining center
EC-630
Retail Price
Market price
Supplier:
Haas Automation
Mainland China
Weight
Stock surplus
隐藏域元素占位
- Product Description
- Product specifications and models
-
- Brand: Haas
- Commodity name: 4-axis CNC machining center
- 型号: EC-630
- 供应商: Haas Automation
- 地址: Mainland China
The EC-630 is designed for high-volume production and unattended operation of large parts and tombstones, featuring 50 taper machining capabilities and a wide machining range. It is equipped with a full 4th axis rotary table system for synchronous movement and a rear chip conveyor for efficient chip control.
The travel is 40" x 37" x 40" (1016 x 940 x 1016 mm)
It has a built-in pallet changer and is equipped with a 630 mm pallet.
Full 4th axis rotary table system -
Number of Axes 4 Axes Horizontal/Vertical Horizontal Structure Rotary Table Spindle Head BT50 Number of Tools 50 Tools Application Used for large workpieces Other Features With pallet changer X-axis 1,016 mm(40 in) Y-axis 889 mm(35 in) Z-axis 1,016 mm(40 in) Speed 7.500 rpm(47,124 rad.min-1) Output Power 22.4 kW(30.46 hp) X-axis Feed Rate 18 m/min Y-axis Feed Rate 18 m/min Z-axis Feed Rate 18 m/min Tool Weight (Max.) 13.9 kg(30.6lb) Tool Change Time 4.2s Total Weight 12,700.6 kg(28,000.03 lb)
Previous Page
Next Page
Product specifications and models
| Number of Axes | 4 Axes |
| Horizontal/Vertical | Horizontal |
| Structure | Rotary Table |
| Spindle Head | BT50 |
| Number of Tools | 50 Tools |
| Application | Used for large workpieces |
| Other Features | With pallet changer |
| X-axis | 1,016 mm(40 in) |
| Y-axis | 889 mm(35 in) |
| Z-axis | 1,016 mm(40 in) |
| Speed | 7.500 rpm(47,124 rad.min-1) |
| Output Power | 22.4 kW(30.46 hp) |
| X-axis Feed Rate | 18 m/min |
| Y-axis Feed Rate | 18 m/min |
| Z-axis Feed Rate | 18 m/min |
| Tool Weight (Max.) | 13.9 kg(30.6lb) |
| Tool Change Time | 4.2s |
| Total Weight | 12,700.6 kg(28,000.03 lb) |
Product Introduction
The EC-630 is designed for high-volume production and unattended operation of large parts and tombstones, featuring 50 taper machining capabilities and a wide machining range. It is equipped with a full 4th axis rotary table system for synchronous movement and a rear chip conveyor for efficient chip control.
The travel is 40" x 37" x 40" (1016 x 940 x 1016 mm)
It has a built-in pallet changer and is equipped with a 630 mm pallet.
Full 4th axis rotary table system
